Applied Fin Tubes

Applied fin tubes are made through tension winding a copper, iron, stainless steel, or aluminum strip on the tube.

The strip is then welded where the fin begins and ends. Our machining is so precise, with constant pitch, that two tubes side by side can interlock.
Applied fin tubes
Valtecno
Tube Material Wall Thickness Tube Diameter Tube Length
All types Min. 1 mm
0.039 in		 10 / 250 mm
0.39 / 9.84 in		 Max. 6500 mm
255.9 in
Fin Material Fin Strip Thickness Fin Pitch Production Capacity
Copper, iron, stainless steel and aluminum From 0.4 to 0.5 mm
From 0.015 to 0.019 in.
Depending on the strip material, also thickness of 0.8 mm / 0.03 in.
 		 From 50 to 500 fins/meter
From 1 to 12 fins/inch		 400 m per day

Applications

Applied fin tubes are used in cooling and/or heating systems

Packaging

We offer different packaging solutions in order to meet your needs:
  • ISPM 15 wooden crates
  • wooden cages
  • industrial wire baskets
